Please note picture is representative of the item but may be different. Always refer to product description for actual product details.
NCE
NCE DCC 5240156 D16MTC HO Decoder 6 Function 21 Pin MTC Plug
Scale: HO
SKU: NCE5240156
NCE DCC 5240156 D16MTC HO Decoder 6 Function 21 Pin MTC Plug
Direct plug in to locos equipped with 21 pin MTC plug with eight functions.
Dimensions: 0.900 x 0.615 x .180 inches – 23 x 16 x 4.7 mm
Silent Running with torque compensated motor drive
Motor rating .75 Amp continuous, 1.2 Amp stall
All eight function outputs have lighting effects generators
Select from 15 different lighting effects
Support for both EU (logic) and US (full power) functions on outputs 5-8
Full support for LED lighting
Decoder programming lock mechanism
Lombard Hobbies - Modelers helping Modelers for almost 50 Years!
